Capsule EndoscopyThe capsule has a frame rate of 3 frames per second, providing images of the small bowel for an in-depth diagnosis.
|
![]() |
![]() |
SwallowingMirocam's size of 10.8mm x 24.0mm is easier to swallow.
|
MiroCam captures and delivers the highest quality images with a resolution of 102,400 pixels (320x 320 pixel image resolution). Optimised imaging is provided through automatic brightness control while 6 white LED lights enable clearest image quality.
A key clinical concern of capsule endoscopy is an incomplete examination (i.e. failure to image the entire small bowel due to a short operation time). Mirocam's 11 hour operation time effectively mitigates this concern, while also capturing more images per second for a thorough diagnostic review of the small bowel.
Mirocam's higher frame rate of 3 images per second significantly increases the chance of observing all findings as the capsule passes through the GI tract.
Mirocam's precision lens provides a 170 degree field of view, enabling exceptional visual coverage of the small bowel mucosa.
Mirocam's size of 10.8mm x 24.0mm is easier to swallow.
The core technology behind the image data transmission is IntroMedic's patented HBC (Human Body Communication) technology.
SPECIFICATIONS | |
---|---|
Capsule Size | 10.8 x 24mm |
Weight | 3.25g |
Light | 6 White LED |
Field of View | 170° |
Viewing Depth | 3.0cm |
Detectable Range | Under 0.1mm |
Sampling Ratio | 3.0 fps |
Working Time | 11 hours |
Chemical Safety | pH 2.0 ~ pH 8.0 |
Battery Type | Silver Oxide Cell |
Operation Temperature | 20-40°C |
Storage Temperature | 0-50°C |
